    Kaishan Brand KY100/KG910B Crawler Portable DTH Drilling rig

    Ask Lasest Price
    Brand Name : Jinquan
    Certification : ISO9001:2008
    Model Number : KY100/KG910B KY125/KG920A(B) KY130/KG930B KY140 (KG940)
    Price : $20000
    Delivery Time : Within 15 days upon receipt of your 30% deposit
    Payment Terms : T/T, Western Union, Paypal, L/C At Sight
    Supply Ability : 100,000 pcs per month
    • Product Details
    • Company Profile

    Kaishan Brand KY100/KG910B Crawler Portable DTH Drilling rig

    Kaishan KY100 Portable Crawler DTH Drilling Rig:
    1.Hole diameter:80-105mm
    2.Weight:3300kg
    3.Bore depth:20m
    4.Dimension:4100*2030*2020mm
    KY100 Specification

    Rock hardness

    		f=6~20Ground clearance(mm)254

    Hole dimater(mm)

    		80~105Walking speed(Km/h)0-2.0
    Hole depth(m)20Drill arm lift angle-35°~+60°
    Work pressure(MPa)0.5~0.7Drill arm swing angle-
    Pressure consumption(m^3/min)≥10Carriage lift angle-11.5°~+36.5°
    Rotate speed(rpm)0~65carriage pitch angle-118.5°~+23.5°
    Lifting force (KN)15Carriage compensation(mm)900
    Drill pipe dimension(mm)60x2000Overall dimension(mm)4100x2030x2020
    Climing capacity30°Weight(Kg)3300
    RemarkGas-liquid linkagePowerYC2108(33Kw 2200r/min)

    Auxiliary power: LGCY10/10,LGCY-12/10 Air Compressor


    Model

    Capacity
    (m3/min)

    Working Pressure(bar)

    Diesel Engine
    (kw)

    Dimension
    (mm)

    LGCY-10/10

    10

    10

    4BTA3.9-C125,93kw

    3900×1920×1900


    LGCY-12/10

    12

    10

    YC6B150Z-K20,110kw

    4080×1980×2350
