Hot Sales Top Quality DTH Rotary Drilling Rig KY120 Blast Hole Drill Rig

Factory sales good quality DTH rotary drilling rig KY120 blasting hole drilling rig:

1.crawler walking

2.can drill 115mm diameter hole

3.diesel driven

KY Crawler Drill series are specially designed drill equipment, which can be widely used for surface drilling such as quarry, railway construction , road construction, small to medium mining operation and etc. High performance features higher penetration rate with lower fuel consumption . Compressed air is used to operate crawler drill hammer for blast holes drilling , bench hole drilling , grout hole drilling , anchor hole drilling and etc.

The Specification of KY120:

Rigidity rock	F=6-20
Diameter of hole	105-120mm
Optium drilling depth	25m
Working pressure	10-14bar
Air consumption	≥13m³/min
Torque	1400 N .m
Rotation speed	0-65rpm
Lift power	17KN
Dimension(KY120)	510020302020mm
weight	3300 KG
Drive system	YC2108 Engine
Standard Components ( option)
1.hammer	DHD340
2.pipe	Φ602000mm, Φ603000mm
3.bit	Φ105(Φ90,Φ115)
4.air hose	Φ381P20
Recommended compressor	LGCY-15/13 (Φ105-Φ115) LGCY-13/13 (Φ90-Φ105)
